Description
Model: CSD-2000
Feature:
- Reed switch 106 x 36.5 x 10mm
- Magnet 106 x 15.5 x 16mm
- Bracket 107 x 50 x 50mm
- Gap 65mm
- Extra wide gap
- 350mm armoured cable (stainless)
- Robust constructed and epoxy sealed to ensure that there is no corrosion
- Universal mounting with L bracket
Specs:
- Contact: NC, SPST
- Rating (max): 10W
- Voltage (max): 100VDC
- Current (max): 500mA
- Reed: Epoxy sealed
- Dimensions:
- Armoured cable: 630mm
- Reed switch: 106 x 36 x 10mm
- Magnet: 106 x 15 x 16mm
- Bracket: 106 x 50 x 50mm
- Gap: 50mm
